5G NR NSA Solution (EN-DC) and IMS Voice service

  • To support Voice service in 5G NR network supporting NSA (EN-DC, Option 3x), VoLTE (Voice over LTE) is used.

  • VoLTE indicates a scenario where the E-UTRA network supports voice services and the EPC offers a connection to IMS.

  • To support VoLTE, two EPS bearers with the following QoS Class Identifier (QCI) values are used:
    –A Default Bearer for IMS signaling (QCI5)
    –A Dedicated Bearer for Voice over LTE (QCI1) .

  • In EN-DC configuration, The MN(Master Node) i.e. eNB prevents the voice data bearer (QCI1)from being configured as a split bearer.

  • This is recommended for disallowing split bearer configuration, e.g. QCI9 (download and upload from the Internet) when the device has a VoLTE connection.

  • Here I try to depict an EN-DC (Option 3x) configuration where the device has two IMS bearers (Signaling and voice) and as well as Internet connection. In this diagram split bearer configuration is allowed when UE has a VoLTE connection.
