Is there any feature in Nokia to push LTE traffic from low band to high bands?

4G LTE
,
1

Hi Experts.

Is there any feature in Nokia to push LTE traffic from low band to high bands?

Admin note: this post was updated with image below.

LTE traffic from low band to high bands
LTE traffic from low band to high bands1280×953 129 KB

2

In the Ericsson feature name is “LTE Inter-Frequency Handover to Higher Priority”, try search similar Name in Nokia CPIs.

3

Actually no access to Nokia CPI…

Can I ask if you have tried this feature and whether it pushed a good amount of traffic from low band to high bands?

4

Yes.

The feature working very fine in Ericsson Network, realy Traffic steering from low band to high band.

5

You can use AMLE from Low bands to High or adjust LNHOIF A5 Thresholds.

6

Check for LBIFHOA5THLD1 and LBIFHOA5THLD1.

Define the RSRP value threshold A5 event which is use for inter frequency handover.

It help to compare frequency of serving cell and target cell of other frequency and decide for best possible layers as per setting.

Setting threshold 1 is serving cell and threshold 2 is target cell.

LTE traffic from low band to high bands
LTE traffic from low band to high bands1280×953 129 KB

Check Nokia Parameter and some value check for your network and adujust the setting

7

Many thanks for the details.

One question: if threshold 1 on low band is -116 then high band coverage would be most likely be very low?

Did you have good amount of traffic shift with this setting?

8

This just an example…

You can make changes as per your requirement in your network.
