RRU comparison: 2T2R with MIMO2x2 vs 4T4R with MIMO2x2 feature

[5G_Understanding]

Hello dear Experts.

Could you clarify please next thing:

• Comparing RRU with 2T2R with MIMO2x2

• With RRU with 4T4R with MIMO2x2 feature

Does it mean that second RRU would give better coverage or throughput?

lf so, how much?

Any suggestions?

[Elnaz]

Hi Dear.

4T4R High throughput you have because you can send 4 different data in each port, so throughout will improve.

Coverage is related to power per port.

[sghoslya]

@5G_Understanding

• Comparing RRU with 2T2R with MIMO2x2
• With RRU with 4T4R with MIMO2x2 feature

Better coverage and same throughput.

@Elnaz

Coverage is related to power per port.

Coverage also means covering the black holes.

[mandersen]

@Elnaz

Coverage is related to power per port.

This is a very common misunderstanding.

[Elnaz]

If power of 2T2R per port is same as 4T4R, coverage will not be impacted.

[mandersen]

Coverage is mostly challenged on Uplink (not Downlink).

So you achieve better coverage per site by having higher gain antennas and more receivers.

So 2T4R has better coverage than 2T2R.

[5G_Understanding]

@Elnaz

4T4R High throughput you have because you can send 4 different data in each port, so throughout will improve.

They both have MIMO2x2. Difference is only about number of antenna ports.

@mandersen

This is a very common misunderstanding.

Why?

[Elnaz]

@5G_Understanding

They both have MIMO2x2. Difference is only about number of antenna ports.

Yes, I thought the question was MIMO 4T4R and 2T2R.

[mandersen]

@5G_Understanding

Why?

Many engineers think that increasing the Downlink output power (Watt) results in increased the coverage.

However, as I said, the problem is usually on Uplink.

Because mobile networks are supposed to be 2-way communication.

So the base station may be able to boost its output to 20 or 40W power - but that does not increase the output of the phone (usually around 1 to 2W).

[5G_Understanding]

Uplink is almost always a bottleneck😞

[5G_Understanding]

Now… what if next configuration:

1. RRU 2T2R MIMO2x2.
   Power per port 20W.

2. RRU 4T4R MIMO2x2.
   Power per port 10W.

So, total RRU power in both cases are the same.

Coverage and throughput the same?

No diversity gain resulting in better coverage and throughput ?

[Azamat_Kenzhetaiuly]

@5G_Understanding

RRU 4T4R MIMO2x2

Hi, could you clarify what do you mean by “RRU 4T4R MIMO2x2”?

Are you using only 2 port of 4T4R RRU?

As I understand you are using all 4 ports, so should be MIMO4x4.

[5G_Understanding]

As I know, not always RRU with 4 RF ports means MIMO4x4 capability.

[Firas_Attar]

@Azamat_Kenzhetaiuly

clarify what do you mean by “RRU 4T4R MIMO2x2”

Yes, he can do that.

@5G_Understanding

• RRU 2T2R MIMO2x2.
  Power per port 20W.
• RRU 4T4R MIMO2x2.
  Power per port 10W.

4T4R throughput is going to be better.

[deepakj]

@mandersen

Many engineers think that increasing the Downlink output power (Watt) results in increased the coverage.

However, as I said, the problem is usually on Uplink.

Because mobile networks are supposed to be 2-way communication.

So the base station may be able to boost its output to 20 or 40W power - but that does not increase the output of the phone (usually around 1 to 2W).

That’s true!

It even create Downlink and Uplink imbalance and UE lost due to poor coverage starts increasing.

[Sivas_Viswa]

@5G_Understanding

• Comparing RRU with 2T2R with MIMO2x2
• With RRU with 4T4R with MIMO2x2 feature

Any specific vendors?

[sghoslya]

@Firas_Attar

4T4R throughput is going to be better.

No, will not.

[shamshad]

@5G_Understanding

• RRU 2T2R MIMO2x2.
  Power per port 20W.
• RRU 4T4R MIMO2x2.
  Power per port 10W.

Coverage will be better for 2T2R.

[Firas_Attar]

@sghoslya

No, will not.

Why not?

[5G_Understanding]

@Sivas_Viswa

Any specific vendors?

Secret vendors doesn’t matter.
