VoLTE / IMS - Analysis Challenge

It’s challenge time, this time we’re going to be looking at an IMS PCAP, and answering some questions to test your IMS analysis chops!

Here’s the packet capture:

IMS_PCAPsDownload PCAPs

Easy Questions

  • What QCI value is used for the IMS bearer?
  • What is the registration expiry?
  • What is the E-UTRAN Cell ID the Subscriber is served by?
  • What is the AMBR of the IMS APN?

Intermediate Questions

  • Is this the first or subsequent registration?
  • What is the Integrity-Key for the registration?
  • What is the FQDN of the S-CSCF?
  • What Nonce value is used and what does it do?
  • What P-CSCF Addresses are returned?
  • What time would the UE need to re-register by in order to stay active?
  • What is the AA-Request in #476 doing?
  • Who is the(opens in a new tab)(opens in a new tab)(opens in a new tab) OEM of the handset?
  • What is the MSISDN associated with this user?

Hard Questions

  • What port is used for the ESP data?
  • Which encryption algorithm and algorithm is used?
  • How many packets are sent over the ESP tunnel to the UE?
  • Where should SIP SUBSCRIBE requests get routed?
  • What’s the model of phone?

The answers for each question are on the next page, let me know in the comments how you went, and if there’s any tricky ones!

Answers: :point_down:
